USG-261 EO gimbal
The USG-261 gimbal is our smallest and lightest solution, specifically for small UAVs of any configurations. It is equipped with a lightweight Full HD high-quality camera. USG-261 weighs only 400 grams but has all the advantages of a full-size gimbal.
Dimensions: 90x119 mm. Weight: 300 g.
TECHNICAL SPECIFICATIONS
Daylight camera: Full HD with 10x optical zoom and 3x digital zoom
Resolution: 1920x1080Sensor Type: CMOS
Field of View: 63.7° to 2.3°
360° continuous rotation
Dimensions (L×H): 90x119 mm
Weight: 300 gEnvironmental Protection: Weather-resistant
Operating Temperature: –25°C to +55°C
FEATURES
Digital video stabilization
Object tracking
Onboard recording
Automatic focus control
Antifog feature
ICR (Infrared Cutfilter Removal) filter
PLUG-AND-PLAY SOLUTION
The USG-261 is compatible with most modern UAV platforms and can be integrated quickly – even in cases involving custom mounts or software environments.
● No coding or scripting required
● Minimal additional configuration
● Intuitive interface – no prior training needed
● Complete technical documentation included
● Ready to operate straight out of the box
Video Processing Block
Dimensions: 98х67х48 mmWeight: 200 g
RTP IP-streaming
Ardupilot Compatible
USG-261 KEY FEATURES
Ultra-Lightweight – Only 300 g
Optimized for micro and small UAVs.The system’s minimal weight preserves flight time and maneuverability, even on ultra-light airframes.
High-Quality Zoom Optics
Equipped with a Full HD afocal zoom lens, the USG-261 delivers smooth magnification and clear visual targeting of distant objects – even under low light conditions.
Stabilization & Target Tracking
The onboard system automatically locks onto targets, stabilizes the video feed, and delivers fluid imagery even under platform vibration or motion.
Control is intuitive – responsive in real-time via touchscreen or joystick.
Integrated Payload Software Suite
Included with the gimbal is specialized software designed to maximize performance and control:
The integrated Video Processing Block manages signal stabilization, object tracking, and live IP-streaming.
The software is easily integrated into existing operator systems, with options to customize for mission-specific needs – all via a clean, user-friendly interface.
Need More Advanced Mission Capabilities?
Our extended software ecosystem includes end-to-end tools for ISR: data collection, real-time analysis, post-processing, and secure transmission. Each module enhances your infrastructure – ensuring successful operation under any conditions.
